Echocel Junior - Traditional

A hand proofing system for flexo inks. This system comes with your choice of rolls.

Incorporating Harper Platinum® laser engraved ceramic anilox technology, a steel doctor blade and a solvent-resistant rubber roll this system has been field-tested for years by flexo printers.

Features:

Designed for water based, solvent and UV inks
Lightweight
Ink path width: 2.75 inch (70mm)
Traditional Rolls are engraved at a 60º Hex

Echocel Junior - Viscous

A hand proofing system for thick or metallic flexo inks.

Incorporating Harper Platinum® laser engraved ceramic anilox technology, a steel doctor blade and a solvent-resistant rubber roll this system has been field-tested for years by flexo printers.

Features:

Designed for thick or metallic inks
Lightweight
Ink path width: 2.75 inch (70mm)
Rolls are engraved at a 30º Hex

Both units are easy to take apart and re-assemble - makes clean-up and roll changes quick and efficient.

Comes with detailed manual, (1) disposable pipette, (3) spare doctor blades, (1) hex key for blades and sturdy, custom-fitted and padded carrying case.

When placing your order, you will need to choose an anilox roll. The chart below gives the specifications for the available rolls.

Rolls 1T through 13T are standard single line screen rolls. Rolls 14T through 19T are standard banded line screen rolls.

Roll	Line Screen Cell/Inch	Volume BCM/Inch	Line Screen Cell/cm	Volume Cm/m
1T	1000	1.25	397	1.94
2T	900	1.45	354	2.2
3T	800	1.8	315	2.8
4T	700	2.2	276	3.4
5T	600	2.5	236	3.9
6T	550	3	217	4.6
7T	500	3.2	197	5
8T	440	3.4	173	5.3
9T	400	3.7	157	5.7
10T	360	4.3	142	6.7
11T	300	4.8	118	7.4
12T	260	5.7	102	8.8
13T	200	6.8	79	10.5
Banded Rolls
14T	900 800	1.45 1.8	354 315	2.2 2.8
15T	700 600	2.2 2.5	276 236	3.4 3.9
16T	550 500	3.0 3.2	217 197	4.6 5
17T	440 400	3.4 3.7	173 157	5.3 5.7
18T	360 300	4.3 4.8	142 118	6.7 7.4
19T	260 200	5.7 6.8	102 79	8.8 10.5
