The eXact Advanced is a spectrophotometer that ensures ink labs, quality control labs and manufacturing partners who must achieve the highest quality with the broadest toolset. Enables printers and packaging converters to truly understand, control and manage color across the entire color network, ensuring the utmost in color accuracy.

Measuring the Color Network from Ink Kitchen to Pressroom

X-Rite eXact™ is a next generation handheld color measurement solution that takes into account the new business needs and dynamics of a global supply chain. X-Rite eXact enables printers and packaging converters to truly understand, control and manage color across the entire color network, ensuring the utmost in color accuracy.

A Single Platform - 3 Models to Choose From

X-Rite eXact Densitometer:

For CMYK operations that want a set of traditional tools and the option to add more features as their requirements change.

X-Rite eXact Standard:
A spectrophotometer that ensures accurate printing of both CMYK and spot colors as well as leveraging industry standard for process control.

X-Rite eXact Advanced:
A spectrophotometer that ensures ink labs, quality control labs and manufacturing partners who must achieve the highest quality with the broadest toolset.

Aperture sizes to meet all applications:

With a choice of 4 different aperture sizes (1.5, 2, 4 or 6 mm) operations can measure across a range of application in print and packaging.

Support for All Measuring Conditions

Using a simple process, eXact fully supports all measuring conditions with one platform, measuring M0, M2 and M3 with a single pass, saving the time and aggravation of measuring each individually.

Measurement Conditions & Filters

M0: No Filter, UV included
M1: Part 1, first in the industry with D50 (Daylight) through the entire visible spectrum
M2: UV Cutoff Filter, UV excluded
M3: Polarization Filter

With X-Rite eXact Get To Color in ONE CLICK

X-Rite eXact is an industry first - a technology platform that combines unique hardware and software into a single, integrated scalable solution that offers:

An intuitive color touch-screen display, an industry first that simplifies device operation
A range of product configurations that scale to meet business needs
Color pass/fail reporting against industry standards, including ISO, JPMA, G7 and PSO
Enhanced device capabilities through the use of Color iQC Print, PantoneLIVE, InkFormulation and/or NetProfiler
Un-tethered calibration, specification and data capturing allows operators to work effectively anywhere on the production floor
Embedded Pantone libraries, for access to industry-leading color reference standards
Expanded on-device storage, allowing job presets and color libraries to be saved and ready for use, accessible with a single click
BestMatch integrates multiple Pantone libraries or custom colors, offering a fast, easy way to accurately measure ink colors throughout the press run, with recommendations for density and other adjustments

Compare

xrite exact compare

Documents:

eXact User Guide

FAQs:

Using the BestMatch Function

Patch / Aperture Size requirement

M0, M1, M2, and M3 measurement conditions

Firmware:

eXact Firmware v2.4.2142

Software:

eXact Manager v1.4.3258

WARRANTY

FEATURES

Specifications

Short Term Repeatability - White	0.05 ΔEab (standard deviation) White BCRA (Error compared to mean value of 10 measurements every 5 seconds)
Short Term Repeatability - Density	'+/- 0.01 D for CMYK (Status E or Status T measurements, maximum error compared to mean value of 10 measurements every 5 seconds at 2.0 D except for M3 Yellow at 1.7 D)
Measurement Geometry	45°/0° ring illumination optics, ISO 5-4:2009(E)
Inter-Instrument Agreement	Average: 0.25 ΔEab, Max: 0.45 ΔEab (for M3: 0.55 ΔEab) (Measurements using X-Rite manufacturing standards at a temperature of 23°C +/- 1°C, 40-60% RH for all measurement modes on 12 BCRA color tiles and a white ceramic reference (D50, 2°))
Light Source	Gas filled tungsten (illuminant type A) and UV LED
Measurement Conditions	M0, M1 (part 1) , M2, M3
Measurement Time	< 1 sec
Spectral Analyzer	DRS spectral engine
Spectral Interval	10 nm
Spectral Range	400 nm to 700 nm
Spectral Reporting	400 nm to 700 nm with 10mm interval
Color Differences	CIE ∆E* (1976), ∆ECMC, CIE ∆E* (2000), and CIE ∆E* (1994)
Color Spaces	CIE Lab, CIE LC*h°, CIE XYZ and Yxy
Illuminants	A, C, D50, D55, D65, D75, F2, F7, F11, D12
Observers	2° and 10°
Humidity	30 to 85% RH (non-condensing)
Operating Temperature Range	10°C to 35°C 50°F to 95°F
Storage Temperature Range	-20° to 50°C -4° to 122°F
Dimensions (length, width, height)	18 cm x 7.8 cm x 7.6 cm 7.1" x 3.1" x 3.0"
Weight	700 g 1.6 lbs.
3rd Party Software Supported	X-Rite ColorCert, X-Rite Color iQC, X-Rite InkFormulation, X-Rite NetProfiler and many others
Communication Interface	USB 2.0 Bluetooth (optional) - Class II
Configuration Options	Bluetooth, NetProfiler
Instrument Display	Color touch-screen, 320 x 240 pixels
Languages Supported	Chinese Simplified, Chinese Traditional, Czech, Danish, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenian, Spanish, Swedish, Turkish
Software Development Kit	Yes
Software Modes	Densitometer, Standard, Advanced
User Experience	Start-up wizard, configurable
Battery	Lithium Ion, 7.4VDC, 2200mAh
Voltage	12 VDC @ 2.5 A
Sample/Measurement	Max. 5000 samples
Standards	More than 20'000 standards (incl. data for all M modes)
Density Range	0.0 D – 3.0 D
Density Standards	Status A, E, I, T and G
Industry Standards	ISO 5-4:2009(E), ISO 13655:2009
BestMatch Feature	Yes
Calibration	Automatic on integrated white reference
Embedded NetProfiler Support	Yes
G7 Certification	Yes
NetProfiler Support	Yes
PantoneLIVE Support	Yes
Pass / Fail	Yes
Warranty	1 year
What's Included?	USB cable, power supply, CD with software and documentation, docking/charging station, quick start guide, carrying case, device certificate
Macintosh	MacOS X 10.8, 10.9, 10.10, 10.11
Windows	Windows XP (32bit), Windows 7 (32 and 64 bit), Windows 8 (32 and 64 bit), Windows 10 (32 and 64 bit)

AVAILABILITY

Available for shipment in 3-5 business days
